QY16d
Hydraulic mobile crane
| Max.Rated
Lifting
Capacity |
kg |
16000 |
| Max.Lifting
Height |
m |
38.5 |
| Main
Boom |
m |
9.8 |
| Jib |
m |
7.5 |
| Max.Hoisting
Moment |
kN.m |
686 |
| Max.Lifting
Rope Speed |
m/min |
100 |
| Slewing
Speed |
r/min |
2.5 |
| Outline
Dimension |
m |
11.9*2.5*3.35 |
| Weight
Data |
t |
24 |
| Chassis
Model |
|
XZ16C |
| Diesel
Model |
|
D6114 |
ZQ33A |
| Max.Power
of Engine |
kW/(r/min) |
152 |
2200 |
| Max.Torque
of Engine |
N.m/(r/min) |
790 |
1400 |
| Min.Turning
Diameter |
m |
|
20 |
| Max.Gradeability |
% |
|
24 |
| Max.Travelling
Speed |
km/h |
67 |
70 |
| Approach
Angle |
° |
|
21 |
| Angle
of Departure |
° |
|
10 |
| Outriggers
Distance |
m |
|
4.6(?)*5.4(?) |
|
